Chapter 1
1-30
4. Main Menu Settings
Main menu items are described in the following tables.
T-1-13
[Paper Settings]
T-1-14
Setting Item Description, Instructions
[Paper Cut] Displayed if a roll is loaded.
Choose Yes to cut the roll at the current position. The paper will be fed, if necessary, so that the sheet is at
least 10 cm (39.4 in.)long after the cut. The paper will not be cut if there is not enough paper left to feed the
paper this much.
[Rep. Ink Tank] When exchanging the ink tank, choose Yes and follow the instructions on the screen.
[Head Cleaning] Specify Printhead cleaning options.
Choose Head Cleaning A if printing is faint, oddly colored, or contains foreign substances.
Choose Head Cleaning B if no ink is printed at all, or if printing is not improved by Head Cleaning A .
[Paper Settings] Specify the type and size of paper.
[Paper Details] Specify detailed paper-related settings, including the ink drying time and borderless printing options.
[GL2 Settings] Make settings for making prints using HP-GL2.
[Adjust Printer] Adjust the Printhead alignment or amount of feed by printing a test pattern.
[Interface Setup] Configure the network settings.
[Maintenance] Replace the Printhead , prepare to transfer the printer, and clean the Pick Up Roller .
[System Setup] Specify the printer system settings, including the date format and display language.
[Test Print] Choose Status Print to print information about the printer.
Choose Media Details to print the paper settings as specified in Med.Detail Set. .
Choose Print Job Log to print a record of print jobs, including the paper type and size, amount of ink used,
and so on.
Choose Menu Map to print a list of the main menu options.
Choose Nozzle Check to print a test pattern for checking the nozzles.
If you have selected a leading edge margin of 20 mm in Nr End Sht Mrgn in the printer menu, the test print
sheet may not be printed completely.
[Information] Displays the information about the printer and history of print jobs.
Setting Item Description, Instructions
[Manual PaperType] Choose the type of manual feed paper.
[Manual PaperSize] Choose the size of manual feed paper.
[Roll Media Type] Choose the type of roll.
[Chk Remain.Roll] Choose On to print a barcode at the end of a roll before you remove it. The printed barcode can be used in
managing the amount of roll paper left. Choose Off if you prefer not to print the barcode.
[Roll Length Set] Displayed if Chk Remain.Roll is On .
If a barcode is not printed on rolls, specify the roll length. The roll length is displayed in meters (1.0 - 91.0
m) or feet (1 - 300 ft.), depending on the setting in Length Unit .
To Next Page
