Canon iPF755 - Carriage; Ink Tank Cover (Inside)

Carriage
a.
Angle Adjustment Lever
Use this lever to fine-tune the printer to correct misalignment of printed lines.
b.
Printhead
The printhead is equipped with ink nozzles. The carriage serves a key role in printing.
c.
Printhead Fixer Lever
Locks the Printhead Fixer Cover.
d.
Printhead Fixer Cover
Holds the Printhead in place.
Ink Tank Cover (Inside)
Left Side Right Side
a.
Ink Tank Lock Lever
A lever that locks the Ink Tank in place and protects it. Lift and press down the lever when replacing an Ink
Tank.
