Canon NP6512 - Page 78

CHAPTER 3 EXPOSURE SYSTEM
COPYRIGHT © 1999 CANON INC. CANON NP6512/6612/7120/7130/7130F REV.0 AUG. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
3-30
Figure 3-332 (rear)
Figure 3-333 (front)
[4]
[3]
[3]
[3]
[3]
2) Turn the cable drive pulley [4] so that the
three shafts [3] of the mirror positioning
tool for rear and front is as shown.
