Canon POD Deck Lite-C1 - Adjustment; Actions when Replacing the Parts

5. Fix the Large Pulley on top left of the Compartment.
• 1 Screw (RS tightening; M4x8)
• 1 Washer
1x
6. Attach the Large Pulley and then put the Short Lifter Wire in the groove.
• 1 Parallel Pin
CAUTION:
Put the Short Lifter Wire in the groove F side.
FF
NOTE:
Pull the Short Lifter Wire from bottom left of the Compartment to attach it without slackness.
4. Disassembly/Assembly
81
