Table of water circuit, electrical and electronic spare parts, UE001 to UE018
spare part code position fi g.
UE001 UE003 UE005 UE008 UE009 UE010 UE015 UE018
460-575 3ph 208-230 1ph
208-230 3ph
Water circuit
Fill tank + conductivity meter UEKVASC100 1 9.a
fi ll solenoid and drain tempering valve kit
KITFD11206 KITFD11211 3 9.a
Internal tubing kit UEKT20000M 2 9.a
Plastic humidifi er base UEKBOTTOM0 6 9.a
Plastic humidifi er top UEKTOP0000 7 9.b
Assembled f/d manifold + 230V pump UEKDRAIN02 5 9.a
Electrical and electronics
Display terminal HCTLEYW0w0
(3)
16 9.b
TAM (current transformer) UEKTAM0000 8 9.b
Contactor
UEKCONT100 UEKCONT200 UEKCONT100 UEKCONT200
10 9.b
Power transformer: 208-230-460-575/24 V UEKTR30000 9 9.b
Electronic controller
(1)
UEYxxv0z0i
(2)
12 9.b
Fuse carrier (F1,F2) URKFH10000 11 9.b
Fuse carrier (F3) UEKFH10000 14 9.b
F1 - F2 power fuses URKFUSE100 -
see electrical draw
F4 Transformer secondary fuse URKFUSE500 -
see electrical draw
F3 Pump fuse UEKFUSE200 -
see electrical draw
Connection cable between terminal and
electronic controller
S90CONN002 -
Tab. 9.a
(1) when ordering, as well as the controller code specify the complete code and serial number of the humidifi er.
(2) xx: kg/h ( 01,......65)
v: power supply ( D=230V 1ph, M=460V 3ph, etc )
z: match digit board (8th code number of the card)
i: 0 single package / 1 multiple package
(3) w: match digit terminal (9th code number of the terminal)
Table of spare part codes, Single-phase cylinders UE001 to UE009, electrode and gasket kit
Model UE001 UE003 UE005 UE009
STANDARD disposable cylinders 208/230 Vac 1~, conductivity 350 to 1250 µS/cm BL0S1F00H2 BL0S1F00H2 BL0S2E00H2 BL0S3F00H2
SPECIAL disposable cylinders 208/230 Vac 1~, conductivity 75 to 350 µS/cm BL0S1E00H2 BL0S1E00H2 BL0S2E00H2 BL0S3E00H2
SPECIAL openable cylinders 208/230 Vac 1~, conductivity 75 to 350 µS/cm BLCS1E00W2 BLCS1E00W2 BLCS2E00W2 BLCS3E00W2
208/230 Vac 1~, conductivity 350 to 1250 µS/cm BLCS1F00W2 BLCS1F00W2 BLCS2E00W2 BLCS3F00W2
Electrode and gasket kit 208/230 Vac 1~, conductivity 75 to 350 µS/cm KITBLCS1E2 KITBLCS2E2 KITBLCS2E2 KITBLCS3E2
208/230 Vac 1~, conductivity 350 to 1250 µS/cm KITBLCS1F2 KITBLCS2F2 KITBLCS2E2 KITBLCS3F2
Filter gasket kit KITBLC1FG0 KITBLC2FG0 KITBLC2FG0 KITBLC3FG0
Tab. 9.b
Table of spare part codes, three-phase cylinders UE003 to UE018, electrode and gasket kit
Model UE003 UE005 UE008 UE010 UE015 UE018
STANDARD
disposable
cylinders
208/230 VAC 3~, conductivity 350 to 1250 µS/cm BL0T1B00H2 BL0T2A00H2 BL0T2A00H2 BL0T3A00H2 BL0T3A00H2 --
460 VAC 3~, conductivity 350 to 750 µS/cm BL0T1D00H2 BL0T2D00H2 BL0T2D00H2 BL0T3D00H2 BL0T3D00H2 BL0T3D00H2
575 VAC 3~, conductivity 350 to 750 µS/cm
BL0T2D00H2 BL0T2D00H2 BL0T3D00H2 BL0T3D00H2 BL0T3D00H2
SPECIAL
disposable
cylinders
208/230 VAC 3~, conductivity 75-350 µS/cm BL0T1A00H2 BL0T2A00H2 BL0T2A00H2 BL0T3A00H2 BL0T3A00H2 --
460 VAC 3~, conductivity 75 to 350 µS/cm BL0T1B00H2 BL0T2C00H2 BL0T2C00H2 BL0T3C00H2 BL0T3C00H2 BL0T3C00H2
460 VAC 3~, conductivity 750 to 1250 µS/cm BL0T1D00H2 BL0T2D00H2 BL0T2D00H2 BL0T3D00H2 BL0T3D00H2 BL0T3D00H2
575 VAC 3~, conductivity 75 to 350 µS/cm BL0T2C00H2 BL0T2C00H2 BL0T3C00H2 BL0T3C00H2 BL0T3C00H2
575 VAC 3~, conductivity 750 to 1250 µS/cm BL0T2D00H2 BL0T2D00H2 BL0T3D00H2 BL0T3D00H2 BL0T3D00H2
SPECIAL
openable
cylinders
208/230 VAC 3~, conductivity 75-350 µS/cm BLCT1A00W2 BLCT2A00W2 BLCT2A00W2 BLCT3A00W2 BLCT3A00W2 --
460 VAC 3~, conductivity 75 to 350 µS/cm BLCT1B00W2 BLCT2C00W2 BLCT2C00W2 BLCT3C00W2 BLCT3C00W2 BLCT3C00W2
460 VAC 3~, conductivity 350 to 750 µS/cm BLCT1D00W2 BLCT2D00W2 BLCT2D00W2 BLCT3D00W2 BLCT3D00W2 BLCT3D00W2
460 VAC 3~, conductivity 750 to 1250 µS/cm BLCT1D00W2 BLCT2D00W2 BLCT2D00W2 BLCT3D00W2 BLCT3D00W2 BLCT3D00W2
575 VAC 3~, conductivity 75 to 350 µS/cm BLCT2C00W2 BLCT2C00W2 BLCT3C00W2 BLCT3C00W2 BLCT3C00W2
575 VAC 3~, conductivity 350 to 750 µS/cm BLCT2D00W2 BLCT2D00W2 BLCT3D00W2 BLCT3D00W2 BLCT3D00W2
575 VAC 3~, conductivity 750 to 1250 µS/cm BLCT2D00W2 BLCT2D00W2 BLCT3D00W2 BLCT3D00W2 BLCT3D00W2
Electrode and
gasket kit
Electrode kit 208/230 Vac 3~, 75/350 µS/cm KITBLCT1A2 KITBLCT2A2 KITBLCT2A2 KITBLCT3A2 KITBLCT3A2 --
Electrode kit 208/230 Vac 3~, 350/1250 µS/cm KITBLCT1B2 KITBLCT2A2 KITBLCT2A2 KITBLCT3A2 KITBLCT3A2 --
Electrode kit 460 Vac 3~, 75/350 µS/cm KITBLCT1B2 KITBLCT2C2 KITBLCT2C2 KITBLCT3C2 KITBLCT3C2 KITBLCT3C2
Electrode kit 460 Vac 3~, 350/750 µS/cm KITBLCT1D2 KITBLCT2D2 KITBLCT2D2 KITBLCT3D2 KITBLCT3D2 KITBLCT3D2
Electrode kit 460 Vac 3~, 750/1250 µS/cm KITBLCT1D2 KITBLCT2D2 KITBLCT2D2 KITBLCT3D2 KITBLCT3D2 KITBLCT3D2
Filter gasket kit KITBLC1FG0 KITBLC2FG0 KITBLC2FG0 KITBLC3FG0 KITBLC3FG0 KITBLC3FG0
575 VAC 3~, conductivity 75 to 350 µS/cm KITBLCT2C2 KITBLCT2C2 KITBLCT3C2 KITBLCT3C2 KITBLCT3C2
575 VAC 3~, conductivity 350 to 750 µS/cm KITBLCT2D2 KITBLCT2D2 KITBLCT3D2 KITBLCT3D2 KITBLCT3D2
575 VAC 3~, conductivity 750 to 1250 µS/cm KITBLCT2D2 KITBLCT2D2 KITBLCT3D2 KITBLCT3D2 KITBLCT3D2
Tab. 11.c
