Carel humiSteam Basic - Table of Parameter B1

39
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
11.6 Table of parameter b1
b1 Alarm
relay
oscillation
when “CY”
alarm is
on
Dilution
drain with
contactor
Drain if new request
≤ 2/3 current request
(contact open)
Total drain due to
inactivity
Display of “CL”
& “CP” alarms
Alarm relay activated
if...
Periodical total drain Enable
management of
steam request
signal /external
fan control relay
M14
DEF. 0
OFF
open YES ON, depending on bF ON alarms in progress OFF Disabled
1
ON
open YES ON, depending on bF ON alarms in progress OFF Disabled
2
OFF
closed YES ON, depending on bF ON alarms in progress OFF Disabled
3
ON
closed YES ON, depending on bF ON alarms in progress OFF Disabled
4
OFF
open NO ON, depending on bF ON alarms in progress OFF Disabled
5
ON
open NO ON, depending on bF ON alarms in progress OFF Disabled
6
OFF
closed NO ON, depending on bF ON alarms in progress OFF Disabled
7
ON
closed NO ON, depending on bF ON alarms in progress OFF Disabled
8
OFF
open YES OFF ON alarms in progress OFF Disabled
9
ON
open YES OFF ON alarms in progress OFF Disabled
10
OFF
closed YES OFF ON alarms in progress OFF Disabled
11
ON
closed YES OFF ON alarms in progress OFF Disabled
12
OFF
open NO OFF ON alarms in progress OFF Disabled
13
ON
open NO OFF ON alarms in progress OFF Disabled
14
OFF
closed NO OFF ON alarms in progress OFF Disabled
15
ON
closed NO OFF ON alarms in progress OFF Disabled
16
OFF
open YES ON, depending on bF OFF alarms in progress OFF Disabled
17
ON
open YES ON, depending on bF OFF alarms in progress OFF Disabled
18
OFF
closed YES ON, depending on bF OFF alarms in progress OFF Disabled
19
ON
closed YES ON, depending on bF OFF alarms in progress OFF Disabled
20
OFF
open NO ON, depending on bF OFF alarms in progress OFF Disabled
21
ON
open NO ON, depending on bF OFF alarms in progress OFF Disabled
22
OFF
closed NO ON, depending on bF OFF alarms in progress OFF Disabled
23
ON
closed NO ON, depending on bF OFF alarms in progress OFF Disabled
24
OFF
open YES OFF OFF alarms in progress OFF Disabled
25
ON
open YES OFF OFF alarms in progress OFF Disabled
26
OFF
closed YES OFF OFF alarms in progress OFF Disabled
27
ON
closed YES OFF OFF alarms in progress OFF Disabled
28
OFF
open NO OFF OFF alarms in progress OFF Disabled
29
ON
open NO OFF OFF alarms in progress OFF Disabled
30
OFF
closed NO OFF OFF alarms in progress OFF Disabled
31
ON
closed NO OFF OFF alarms in progress OFF Disabled
32
OFF
open YES ON, depending on bF ON no alarms in progress OFF Disabled
33
ON
open YES ON, depending on bF ON no alarms in progress OFF Disabled
34
OFF
closed YES ON, depending on bF ON no alarms in progress OFF Disabled
35
ON
closed YES ON, depending on bF ON no alarms in progress OFF Disabled
36
OFF
open NO ON, depending on bF ON no alarms in progress OFF Disabled
37
ON
open NO ON, depending on bF ON no alarms in progress OFF Disabled
38
OFF
closed NO ON, depending on bF ON no alarms in progress OFF Disabled
39
ON
closed NO ON, depending on bF ON no alarms in progress OFF Disabled
40
OFF
open YES OFF ON no alarms in progress OFF Disabled
41
ON
open YES OFF ON no alarms in progress OFF Disabled
42
OFF
closed YES OFF ON no alarms in progress OFF Disabled
43
ON
closed YES OFF ON no alarms in progress OFF Disabled
44
OFF
open NO OFF ON no alarms in progress OFF Disabled
45
ON
open NO OFF ON no alarms in progress OFF Disabled
46
OFF
closed NO OFF ON no alarms in progress OFF Disabled
47
ON
closed NO OFF ON no alarms in progress OFF Disabled
48
OFF
open YES ON, depending on bF OFF no alarms in progress OFF Disabled
49
ON
open YES ON, depending on bF OFF no alarms in progress OFF Disabled
50
OFF
closed YES ON, depending on bF OFF no alarms in progress OFF Disabled
51
ON
closed YES ON, depending on bF OFF no alarms in progress OFF Disabled
52
OFF
open NO ON, depending on bF OFF no alarms in progress OFF Disabled
53
ON
open NO ON, depending on bF OFF no alarms in progress OFF Disabled
54
OFF
closed NO ON, depending on bF OFF no alarms in progress OFF Disabled
55
ON
closed NO ON, depending on bF OFF no alarms in progress OFF Disabled
56
OFF
open YES OFF OFF no alarms in progress OFF Disabled
57
ON
open YES OFF OFF no alarms in progress OFF Disabled
58 OFF closed YES OFF OFF no alarms in progress OFF Disabled
59 ON closed YES OFF OFF no alarms in progress OFF Disabled
60 OFF open NO OFF OFF no alarms in progress OFF Disabled
61 ON open NO OFF OFF no alarms in progress OFF Disabled
62 OFF closed NO OFF OFF no alarms in progress OFF Disabled
