Carel humiSteam Basic - Table of Parameter B1

41
ENG
“UE BASIC” +03U0042EN - rel. 1.3 - 10 May 2013
11.6 Table of parameter b1
b1 Alarm relay
oscillation when
“CY” alarm is on
Dilution drain
with contactor
Drain if new
request ≤
2/3 current
request
(contact open)
Total drain due to
inactivity
Display of “CL”
& “CP” alarms
Alarm relay activated
if...
Periodical total drain Enable
management
of steam
request signal
/external fan
control relay
M14
128
OFF
open YES ON, depending on bF ON alarms in progress OFF Enabled
129
ON
open YES ON, depending on bF ON alarms in progress OFF Enabled
130
OFF
closed YES ON, depending on bF ON alarms in progress OFF Enabled
131
ON
closed YES ON, depending on bF ON alarms in progress OFF Enabled
132
OFF
open NO ON, depending on bF ON alarms in progress OFF Enabled
133
ON
open NO ON, depending on bF ON alarms in progress OFF Enabled
134
OFF
closed NO ON, depending on bF ON alarms in progress OFF Enabled
135
ON
closed NO ON, depending on bF ON alarms in progress OFF Enabled
136
OFF
open YES OFF ON alarms in progress OFF Enabled
137
ON
open YES OFF ON alarms in progress OFF Enabled
138
OFF
closed YES OFF ON alarms in progress OFF Enabled
139
ON
closed YES OFF ON alarms in progress OFF Enabled
140
OFF
open NO OFF ON alarms in progress OFF Enabled
141
ON
open NO OFF ON alarms in progress OFF Enabled
142
OFF
closed NO OFF ON alarms in progress OFF Enabled
143
ON
closed NO OFF ON alarms in progress OFF Enabled
144
OFF
open YES ON, depending on bF OFF alarms in progress OFF Enabled
145
ON
open YES ON, depending on bF OFF alarms in progress OFF Enabled
146
OFF
closed YES ON, depending on bF OFF alarms in progress OFF Enabled
147
ON
closed YES ON, depending on bF OFF alarms in progress OFF Enabled
148
OFF
open NO ON, depending on bF OFF alarms in progress OFF Enabled
149
ON
open NO ON, depending on bF OFF alarms in progress OFF Enabled
150
OFF
closed NO ON, depending on bF OFF alarms in progress OFF Enabled
151
ON
closed NO ON, depending on bF OFF alarms in progress OFF Enabled
152
OFF
open YES OFF OFF alarms in progress OFF Enabled
153
ON
open YES OFF OFF alarms in progress OFF Enabled
154
OFF
closed YES OFF OFF alarms in progress OFF Enabled
155
ON
closed YES OFF OFF alarms in progress OFF Enabled
156
OFF
open NO OFF OFF alarms in progress OFF Enabled
157
ON
open NO OFF OFF alarms in progress OFF Enabled
158
OFF
closed NO OFF OFF alarms in progress OFF Enabled
159
ON
closed NO OFF OFF alarms in progress OFF Enabled
160
OFF
open YES ON, depending on bF ON no alarms in progress OFF Enabled
161
ON
open YES ON, depending on bF ON no alarms in progress OFF Enabled
162
OFF
closed YES ON, depending on bF ON no alarms in progress OFF Enabled
163
ON
closed YES ON, depending on bF ON no alarms in progress OFF Enabled
164
OFF
open NO ON, depending on bF ON no alarms in progress OFF Enabled
165
ON
open NO ON, depending on bF ON no alarms in progress OFF Enabled
166
OFF
closed NO ON, depending on bF ON no alarms in progress OFF Enabled
167
ON
closed NO ON, depending on bF ON no alarms in progress OFF Enabled
168
OFF
open YES OFF ON no alarms in progress OFF Enabled
169
ON
open YES OFF ON no alarms in progress OFF Enabled
170
OFF
closed YES OFF ON no alarms in progress OFF Enabled
171
ON
closed YES OFF ON no alarms in progress OFF Enabled
172
OFF
open NO OFF ON no alarms in progress OFF Enabled
173
ON
open NO OFF ON no alarms in progress OFF Enabled
174
OFF
closed NO OFF ON no alarms in progress OFF Enabled
175
ON
closed NO OFF ON no alarms in progress OFF Enabled
176
OFF
open YES ON, depending on bF OFF no alarms in progress OFF Enabled
177
ON
open YES ON, depending on bF OFF no alarms in progress OFF Enabled
178
OFF
closed YES ON, depending on bF OFF no alarms in progress OFF Enabled
179
ON
closed YES ON, depending on bF OFF no alarms in progress OFF Enabled
180
OFF
open NO ON, depending on bF OFF no alarms in progress OFF Enabled
181
ON
open NO ON, depending on bF OFF no alarms in progress OFF Enabled
182
OFF
closed NO ON, depending on bF OFF no alarms in progress OFF Enabled
183
ON
closed NO ON, depending on bF OFF no alarms in progress OFF Enabled
184
OFF
open YES OFF OFF no alarms in progress OFF Enabled
185
ON
open YES OFF OFF no alarms in progress OFF Enabled
186 OFF closed YES OFF OFF no alarms in progress OFF Enabled
187 ON closed YES OFF OFF no alarms in progress OFF Enabled
188 OFF open NO OFF OFF no alarms in progress OFF Enabled
189 ON open NO OFF OFF no alarms in progress OFF Enabled
190 OFF closed NO OFF OFF no alarms in progress OFF Enabled
