Accessories
The air conditioning system comes with the following accessories. Use all of the installation
parts and accessories to install the air conditioner. Improper installation may result in water
leakage, electrical shock and re, or cause the equipment to fail. The items are not included
with the air conditioner must be purchased separately.
Name of Accessories Q‘ty (pc) Shape
Name of
Accessories
Q’ty (pc) Shape
Manual 2~3
Remote controller 1
Drain joint
(for cooling &
heating models)
1 Battery 2
Seal
(for cooling &
heating models)
1
Remote controller
holder (optional)
1
Mounting plate 1
Fixing screw for
remote controller
holder (optional)
2
Anchor
5~8
(depending
on models)
Small Filter
(Need to be installed
on the back of main air
lter by the authorized
technician while
installing the machine)
1~2
(depending
on models)
Mounting plate
xing screw
5~8
(depending
on models)
Name Shape Quantity (PC)
Connecting pipe assembly
Liquid side
ø6.35 (1/4 in)
Parts you must purchase
separately. Consult the dealer
about the proper pipe size of
the unit you purchased.
ø9.52 (3/8in)
Gas side
ø9.52 (3/8in)
ø12.7 (1/2in)
ø16 (5/8in)
ø19 (3/4in)
Magnetic ring and belt
(if supplied ,please refer
to the wiring diagram to
install it on the connective
cable.)
1 2 3
Pass the belt through the
hole of the Magnetic ring
to x it on the cable
Varies by model
Accessories
Page 02-GB
