1-GENERALINFORMATION

Engine

Watercooled,4-cylinders,dieselengineinmountedon

therearchassisinthelongitudinaldirection.Thisen-

gineismanufacturedbyFPTanditdelivers74.5kWat

2200RPM.

PTIL15COM2142AA3

Travelpump

Thisisavariabledisplacementaxialpistonpump.

PTIL14COM0077AA4

Vibrationpump

Thisisavariabledisplacementaxialpistonpump.

PTIL14COM0078AA5

Steeringpump

Thisgeartypesteeringpumpmountedatthesideofthe

enginesupplieshydraulicoiltothesteeringcylinders.

PTIL14COM0079AA6
