1-GENERALINFORMATION
Drumdrivemotor
Thisisalowspeedhightorquemotor.
PTIL14COM0080AA7
Rearaxlemotor
Thisisarearaxlemotor.
PTIL14COM0081AA8
Vibrationmotor
Thisisaxeddisplacementaxialpistontypemotor.
PTIL14COM0082AA9
Steeringunit
Thesteeringunitismountedontheoperator’sstand.This
steeringunitsupplieshydraulicoiltothesteeringcylinders
proportionaltotherotationofthesteeringwheel.Thisunit
isalsocalledasorbitrol.
PTIL14COM0083AA10
