1-GENERALINFORMATION
Productidentication
TheCX75CSRisatotallyhydraulicexcavator.Itconsistsofanundercarriagettedwithtracksandaturntable
bearingwhichsupportstheupperstructureframe.Theupperstructureframesupportstheattachment,atthefrontend
ofthemachine,plustheengine,hydraulicsandcab.Whentheoperatorworksthecontrols,theengine-drivenpump
delivershydraulicuidtothecontrolvalves.Thecontrolvalvesdistributethehydraulicuidtothevariouscylinders
andhydraulicmotorsemployed.Acoolingsystemmaintainsthehydraulicuidatnormaloperatingtemperature.
SMIL13CEX2884EA1
Standardmodel
SMIL13CEX2885EA2
Bladetype
SMIL13CEX2926EA3
Offsetboomtype
