6-MAINTENANCE

Greasepoints(Easymaintenancesystem)

Usingagreasegun,injectgreaseofthespecied

typeinthegreasepointsshowningures:

•

Boombottompin

NOTICE:ifthefollowinglinkagepointisnotequippedwith

originalparts,thispointmustbegreasedevery50hours.

SMIL13CEX2824AB1

•

Boom/armlinkage

SMIL13CEX2825AB2

6-59
