3-CONTROLS/INSTRUMENTS

Enginehood

Opening

Usethestarterswitchkeytounlocktheenginehood

SMIL13CEX2647AB1

Slowlyliftthehooduntilthegasspringisautomatically

xed.

NOTICE:Oncethehoodiscompletelyopened,make

surethelockingsystemiscorrectlyengaged.

SMIL13CEX2648AB2

Closing

WARNING

Movingparts!

Makesurethehoodisclosedproperlybefore

drivingthemachine.

Failuretocomplycouldresultindeathorse-

riousinjury.

W0280A

Lifttheenginehoodslightly,pullbackthebraceunderthe

hood,thenclosethehood.

SMIL13CEX2647AB3

3-48
