Offsetboomcontrols
WARNING
Unexpectedmachinemovement!
ALWAYSlocktheauxiliarypedalswhennotin
use.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0222A
1.Theoffsetboompivotstotheright.
2.Theoffsetboompivotstotheleft.
3.Thepedalislocked.(Placetheprotectiononthepedal
tolockit).
4.Thepedalisunlocked.(Placetheprotectionforwards
tousethepedal).
