CASE CONSTRUCTION CX75C SR - Hydraulic Oil Level

6-MAINTENANCE
Hydraulicoillevel
WARNING
Burnhazard!
Beforeperforminganyserviceonthehy-
draulicsystem,youmustallowittocool.
Hydraulicuidtemperatureshouldnot
exceed40°C(104°F).
Failuretocomplycouldresultindeathor
seriousinjury.
W0241A
Tocheckthehydraulicoillevelproceedasfollows:
1.Placethemachineonat,levelgroundand
placetheattachmentinthepositionshown.
Raisethedozerblade(ifequipped).Stopthe
engineandremovetheignitionkey.
SMIL13CEX2784AB1
2.Theoilshouldbeinthemiddleoftheindicator.
Addmoreoilifnecessary.
SMIL13CEX2785AB2
Fillingthehydraulictank
1.Releaseallpressureinthehydraulicreservoir.
Refertopage6-11.
2.Cleanthecoverplateandtheareaaroundthe
plate.Removethecoverplateandaddhy-
draulicuidtothereservoirasrequired.
3.Replacethecoverplatesealifrequiredand
installthecoverplate.
NOTICE:makesurethatnocontaminant(water,sandetc.)
entersthereservoirduringlling.
SMIL13CEX2786AB3
6-17
