4-OPERATINGINSTRUCTIONS
MOVINGTHEUNIT
Machinetravel
WARNING
Controlscanbereversed!
Inthenormaltravelposition,theoperator's
compartmentisabovetheidlerwheelsandthe
travelreductiongearsaretotherearoftheup-
perstructure.Iftheupperstructureisturned
180degreesinrelationtotheundercarriage,
thecontrolsarereversed.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0289A
NOTE:beforeundertakinganytravel,raisetheattach-
mentandthedozerblade(ifequipped).
NOTE:travelspeeddependsonthetiltingangleofthe
travelcontrolleversandpedalsandthespeedtravel
modeselected.
NOTE:thedifferenttravelcongurationsdescribedhere-
afterarewiththetravelreductiongearstotherearofthe
upperstructure.
NOTICE:ensurethesafetyoftheworkrangebeforeop-
eratingablade.Raisethebladebeforetravelingwiththe
machine.Lowerthebladewhilethemachineisstopped.
Ensurethesafetywhileoperatingtheblade.Also,pay
carefulattentiontotheleveroperation.Becarefulofin-
terferencewiththebladeandbucketwhenfoldingtheat-
tachmentbeforetravelingortransport.
Travelalarm(optional)
Thetravelalarmsoundscontinuouslyorfor10sdepend-
ingonthepositionofthetravelcautionalarmswitch.Re-
fertopage3-34.
SMIL13CEX2677AB1
SMIL13CEX2678AB2
Straightlinetravel(forwardtravel)
Pressthetwopedals(orpushthetwolevers)forwardsat
thesametime.
SMIL13CEX2679AB3
