3-CONTROLS/INSTRUMENTS

OVERHEADCONTROLS

Roofcurtain

Toopentheroofcurtain,slideittowardtherearusingthe

handles.T oclosethecurtainslideittowardthefront.

SMIL13CEX2631AB1

Roofhatch

Opentheroofcurtain.T oopentheroofhatch,operatethe

handleandpushthehandle.T oclosetheroofhatch,pull

thehandleuntilengagement.

NOTICE:Sinceroofhatchopeningisassistedbytwogas

struts,simplyfollowthroughtheclosingmovementwith-

outpullingortryingtoholditback.

SMIL13CEX2632AB1

3-40
