6-MAINTENANCE

Fuses

•

Toaccessthefusebox,openthecoverlocated

behindtheoperator'sseat.

NOTICE:beforechangingfusesorrelays,turntheignition

keytotheOFFposition,waitoneminuteminimumand

placethekeyofthebatterymasterswitchinO(off)position.

Refertopage3-47.

NOTICE:neverreplaceafusewithafuseofadifferent

amperage.

SMIL13CEX2813AB1

•

Toaccessthefuses,removethecoveronthe

box.Anoticeonthecovergivesthefunction

andamperageofeachfuse.

NOTE:toremoveorinstallafuse,usethenotchinthe

upperright-handcornerofthecover.

SMIL13CEX2814AB2

6-78
