5-TRANSPORTOPERATIONS
7.(Machinewithattachment)
Bringthemachinerighttothefrontofthetrailerand
lowertheattachmenttothetrailerbed.
SMIL13CEX2723AB7
7.(Machinewithoutattachment)
Movethemachinerighttothefrontofthetrailer,
swingtheupperstructure.
8.Stoptheengine,removetheignitionkey,thenmove
thegatelocklevertotheneutralposition(withthe
safetybarfacinginside).
9.Makesurethatalldoors,hoodsandaccesspanels
arecorrectlylocked.
10.Foldtherearviewmirrorsinwards.
SMIL13CEX2724AB8
11.Useblocksandchainstofastenthemachineandthe
attachment(ifequipped)tothetrailer.Seepage5-6.
SMIL13CEX2725AB9
*1
Wirerope
*2
Block
*3Stopblock
*4
Padding
5-4
