CASE CONSTRUCTION CX75C SR

To Next Page

To Previous Page

6-MAINTENANCE

Cabheadlight

1.Disconnecttheplug.

SMIL13CEX2833AB5

2.Removethe4screwsandtilttheheadlight.

SMIL13CEX2834AB6

3.Pullthecliptotheoutsideandremovethe

lightbulb.Installanewlightbulbofthesame

wattage(70W).

4.Installtheclip,puttheheadlightbackinposition

andinstallthescrewsandtheplug.

5.Installtheswitchbracket.

NOTICE:neverputyourngersonatungsteniodidebulb.

SMIL13CEX2835AB7

6-75
