8-SPECIFICATIONS
Quickcoupler(Optional)
Dimensionsneededtotthequickcoupler
Bucketpindiameter50mm(1.97in)
Widthbetweenlugs
176mm(6.9in)
Minimumdistancebetweenbucketcentres
290mm(11.4in)
Maximumdistancebetweenbucketcentres
312mm(12.3in)
NOTICE:thequickcouplerdescribedinthismanualisdesignedtobeusedwithCASECONSTRUCTIONbuckets.
Thisbeingsaid,otherbucketsmaybeused,providedthediameterofthepinsandthewidthbetweenthebucketlugs
aremodiedtomeetthedimensionsneededtotthequickcoupler(pins,washers,bushings,etc.).Consultyour
CASECONSTRUCTIONDealer.
Weight:100kg(220.5lb)
Overalldimensions
SMIL13CEX2503EB4
(A)610mm(24.02in)
(B)378mm(14.88in)
(C)312mm(12.28in)
Boomandarm
Standardmodelandbladetype
Boomlength
3.75m(147.64in)
Armlength
1.69m(66.54in)2.19m(86.22in)
Offsetboomtype
Boomlength
3.89m(153.15in)
Armlength
1.75m(68.90in)2.10m(82.68in)
