CASE CONSTRUCTION CX75C SR - Page 246

8-SPECIFICATIONS
1.75m(68.90in)
Arm
Offset0
Maximumoffset(left)
(A)Maximumreach6500mm(255.91in)6080mm(239.37in)
(B)Maximumreachonsurface6360mm(250.39in)5930mm(233.46in)
(C)Maximumdiggingdepth4250mm(167.32in)3830mm(150.79in)
(D)2.44m(96.06in)leveldiggingdepth3870mm(152.36in)3440mm(135.43in)
(E)Maximumdumpingheight5750mm(226.38in)5400mm(212.60in)
(F)Maximumdiggingheight7380mm(290.55in)7040mm(277.17in)
(G)Minimumswingradiusforattachments2130mm(83.86in)1870mm(73.62in)
(H)Maximumdiggingdepthforverticalsurface3330mm(131.10in)2940mm(115.75in)
(I)Maximumdigginglengthforat-bottomditch2440mm(96.06in)2440mm(96.06in)
(J)Offsetright1000mm(39.37in)
(K)Offsetleft1100mm(43.31in)
2.10m(82.68in)
Arm
Offset0
Maximumoffset(left)
(A)Maximumreach6790mm(267.32in)6370mm(250.79in)
(B)Maximumreachonsurface6660mm(262.20in)6230mm(245.28in)
(C)Maximumdiggingdepth4600mm(181.10in)4180mm(164.57in)
(D)2.44m(96.06in)leveldiggingdepth4250mm(167.32in)3820mm(150.39in)
(E)Maximumdumpingheight5750mm(226.38in)5400mm(212.60in)
(F)Maximumdiggingheight7590mm(298.82in)7240mm(285.04in)
(G)Minimumswingradiusforattachments2360mm(92.91in)2090mm(82.28in)
(H)Maximumdiggingdepthforverticalsurface3680mm(144.88in)3280mm(129.13in)
(I)Maximumdigginglengthforat-bottomditch2440mm(96.06in)2440mm(96.06in)
(J)Offsetright1000mm(39.37in)
(K)Offsetleft1100mm(43.31in)
8-14
