CASE CONSTRUCTION CX75C SR

To Next Page

To Previous Page

2-SAFETYINFORMATION

Cautiontotheblade

Partnumber:KHP1384

Becarefuloftheinterferencewiththeattachment.

SMIL13CEX2855AB23

Bladeoperation(bladetype)

Partnumber:KAP0859

Thisdecalshowsthebladeoperation.

SMIL13CEX2856AB24

EmergencyContact

Partnumber:KHP18650

Thisistheemergencycontactnumber.

SMIL13CEX2850AB25

NoWeldingonormodicationstothecab

Partnumber:KHP18640

Thisdecalwarnsthatweldingonormodifyingthecabcan

deteriorateitsstrength.Neverattempttoweldormodify

thecab.

SMIL13CEX2857AB26

2-23
