2-SAFETYINFORMATION

Batterymasterswitch

Partnumber:KHP20210

Thisswitchshutsoffthebatterywhenturnedoffposition.

Refertotheoperatormanualforthedetailedinstructions.

Theswitchisexclusivelyfortheservicepurposesuchas

weldingandelectricalrepairwork.

SMIL13CEX2545AB35

Checkvalve

Partnumber:KHP17390

Thisdecalindicatesthatifthecheckvalveoftherecoil

springisloosened,thevalvemayyout.Itindicatesthat

checkvalvelooseningmustbeperformedcorrectlyafter

readingtheoperator'smanual.

SMIL13CEX2858AB36

Batteries

Partnumber:KHP17430

Thisdecalshowsthatitisnecessarytoconsulttheoper-

ator’smanualbeforehandlingthebatteries.

SMIL13CEX2547AB37

Fuellterreplacement

Partnumber:KHP15770

Thisdecalindicatesthatfuellterreplacementmustbe

performedcorrectlyafterreadingtheoperator'smanual.

SMIL13CEX2556AB38

2-26
