2-SAFETYINFORMATION

Highpressurecommonrail

Partnumber:KHP13160

Thisdecalindicatesthatthehigh-pressurevalveofthe

commonrailmustnotbeloosened,becausetheengine

fuelsystemishighlypressurized.Itindicatesthathigh-

pressurefuelmaysprayoutdangerously.

SMIL13CEX2552AB43

Engineoperation

Partnumber:KHP17440

Thisdecalwarnstheoperatornottostepontheengine.

Itindicatesthatenginemaintenancemustbeperformed

correctlyafterreadingtheoperator'smanual.

SMIL13CEX2553AB44

Tiedownpoint

Partnumber:KHP15201

Thisdecalshowsthetie-downpointsfortransportingthe

machine.

SMIL13CEX2859AB45

Itisforbiddentostandwithintheworkingrangeofthe

upperstructure

Partnumber:KHP17510

Thisdecalremindstheoperatornottoallowanyoneto

standwithintheworkingrangeoftheupperstructurewhile

theengineisrunning(riskofbeingcrushed).

SMIL13CEX2860AB46

2-28
