REF NAME FUNCTION
ENCODER
21
Operations screen /
navigation encoder knob
Press to enter quick adjustment menu. Turn the knob to select items in the menu.
See additional explanation on pages 24-25.
PROGRAMMABLE BUTTONS – shortcut to the AFS Pro 1200
™
screen
22 Return/back screen While in the quick adjustment menu, press the button to return to previous menu or exit.
23 Operations screen shortcut Prompts the Operations screen.
24 EHR screen shortcut Prompts the EHR settings screen.
25 Media/radio shortcut Prompts the media/radio settings screen.
26 Phone screen shortcut Prompts the phone settings screen
27 HVAC screen short Prompts the HVAC settings screen.
HITCH
28
Rear hitch
position control knob
The outside ring of the position control knob adjusts the rear hitch lower limit set point.
The further the operator turns the knob clockwise the higher or shallower the hitch lower
limit will be.
29
Front hitch
position control knob
The inner knob of the front position control knob (if tractor is equipped with) adjusts the
front hitch lower limit set point. The further the operator turns the knob clockwise the
higher or shallower the hitch lower limit will be.
MFD / DIFF-LOCK
30 Manual MFD Enables MFD.
31 Auto MFD
Enables Auto MFD. Pressing and holding for more than 3 seconds prompts the setting
screen for MFD. See additional explanation on pages 26.
32 Manual difock Enables manual difock.
33 Auto difock
Enables Auto difock. Pressing and holding for more than 3 seconds prompts the setting
screen for difock. See additional explanation on pages 26.
NOTE: Difock and MFD engagement is based on the hitch position, brake application, ground speed, the steering
engagement and the amount of wheel slip (see next page).
PTO
34 PTO operator intent
Allows the PTO to keep running if the operator is out of the seat. Button must be pushed
after the PTO switch has been pressed to the “ON” position.
35 PTO aggressiveness Changes the PTO engagement rate from Heavy to Auto.
36 PTO display shortcut Prompts the PTO settings screen.
37 Front PTO engage If equipped – Pressing down on the front of the switch engages the front PTO.
38 Front Auto PTO This feature is not available on this tractor.
39 Rear PTO engage Pressing down on the front of the switch engages the rear PTO.
40 Rear Auto PTO
Turns on the “AUTO” mode (PTO must be engaged rst). PTO engagement is then
controlled by hitch raise/lower commands. Limits are set in the display.
