DISTRIBUTION SYSTEMS - HIGH-FLOW HYDRAULIC POWER SYSTEM
bs04d019_1 2
445/445CT High Flow Hydraulic Installation
1. High flow pump 5. High flow accumula tor 9. High flow pump to valve press ure
hose
2. High flow pump PTO drive adapter 6. High flow oil cooler 10. High flow pump supply hose
3. Loader control valve
7. High flow retu rn tube
4. High flow valve 8. High fl ow pressure tube
1 04/05/2005
A.16.A / 17
