DISTRIBUTION SYSTEMS - HIGH-FLOW HYDRAULIC POWER SYSTEM
Hydraulic pump - Remove (A.16.A.20 - F.10.A.10)
445, 445CT
1. Place a shop towel under the High Flow Pump.
2. Remove the cap
from the h ydraulic reservoir.
CAS1871
3. Co nnect a vac
uum pump to the hydraulic reservo ir.
CAS10192
4. Reservoir -
Apply vacuum (A.10.A.22 - F.35.A.50)
Start the vacuum pump.
5. Tag and disconnect the hose from the fitting at the
suction port of the High Flow Pump.
6. Install a plug in the hose and a cap on the fi tting.
7. Tag and disconnect the hose from the fitting at the
pressure port of the High Flow Pump.
8. Instal
l a plug in the hose and a cap on the fitting.
9. Stop the vacuum pump.
10. Loosen and remove the upper flange mounting
bolt (1) and the lower flange mounting bolt (2) (not
shown) o n the Hig h Flow P ump.
BD04D009_1 1
11. Rem ove the High Flow Pump from th e Engine
mounting location.
1 04/05/2005
A.16.A / 16
