DISTRIBUTION SYSTEMS - ELECTRICA L POWE R SYSTEM
Connector 127A
256346a1 16
Cavity Circuit ID
Description
A
602B (W) To fuel hold-in solenoid
B
622B (W) From ignition key "START" position
1 04/05/2005
A.30.A / 20
