Casio EXILIM EX-Z77 User Manual

116
ADVANCED SETTINGS
Perform the following steps to change the focus mode.
1. In the REC mode, press [MENU].
2. On the “REC” tab, select “Focus” and then
press [X].
3. Use [S] and [T] to
select the focus mode
setting you want and
then press [SET].
An icon appears on the
monitor screen to indicate
the current focus mode.
• See the following pages
of this section for details
about shooting with each
focus mode.
Using Auto Focus
1.
Align the monitor screen’s focus frame with
the subject you want to focus and then half-
press the shutter button.
This camera will perform the focus operation.
You can tell if the image is in focus by checking the
operation lamp and the focus frame color.
Focus mode Icon
Status Operation Lamp Focus Frame
Focusing
Complete
Lit Green Green
Not Focused Flashing Green Red
Focus Frame
Operation Lamp

Casio EXILIM EX-Z77 Specifications

General

Digital SLR	No
Video capability	Yes
Dimensions (WxDxH)	95 x 19.8 x 59 mm
Focal length (35mm film equivalent)	38 - 114 mm
Product color	Pink
USB version	2.0
Display diagonal	2.6 \
Display resolution (numeric)	479 pixels
Compatible memory cards	mmc, sd
Megapixel	7.2 MP
Sensor type	CCD
Image sensor size	1/2.5 \
Digital zoom	4 x
Optical zoom	3 x
Combined zoom	12 x
Focal length range	6.3 - 18.9 mm
White balance	auto, manual
Flash modes	auto, Flash off, manual, Red-eye reduction
Camera shutter type	electronic, mechanical

Weight and Dimensions

Depth	19.8 mm
Width	95 mm
Height	59 mm
Weight	118 g
