174
EDITING IMAGES
MOTION PRINT lets you capture a movie frame and use it to
create a snapshot. The snapshot you create can be either of the
two formats described below.
1. In the PLAY mode, use [W] and [X] to scroll
through images and display the movie that
contains the frame you want to use.
2. Press [MENU].
3. On the “PLAY” tab, select “MOTION PRINT”,
and then press [X].
4. Use [S] and [T] to select either “9 frames” or
“1 frame”.
5. Use [W] and [X] to scroll through the movie
frames and search for the one you want to use
as the image of the snapshot.
Holding down [W] or [X] scrolls at high speed.
Creating a Snapshot of a Movie Frame
(MOTION PRINT)
9-frame
Snapshot
This format puts the
selected movie
frame in the center,
the four frames that
precede it along top
and the four frames
that follow it along
the bottom.
1-frame
Snapshot
This format creates
a snapshot using
the selected movie
frame only.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio EXILIM EX-Z77 and is the answer not in the manual?

Casio EXILIM EX-Z77 Specifications

General IconGeneral
Digital SLRNo
Video capabilityYes
Dimensions (WxDxH)95 x 19.8 x 59 mm
Focal length (35mm film equivalent)38 - 114 mm
Product colorPink
USB version2.0
Display diagonal2.6 \
Display resolution (numeric)479 pixels
Compatible memory cardsmmc, sd
Megapixel7.2 MP
Sensor typeCCD
Image sensor size1/2.5 \
Digital zoom4 x
Optical zoom3 x
Combined zoom12 x
Focal length range6.3 - 18.9 mm
White balanceauto, manual
Flash modesauto, Flash off, manual, Red-eye reduction
Camera shutter typeelectronic, mechanical
Weight and Dimensions IconWeight and Dimensions
Depth19.8 mm
Width95 mm
Height59 mm
Weight118 g
