E-112
4. Before using the cradle ports, remove the caps from the ports.
When using a LAN, connect one end of the LAN cable to the LAN port and the other
end to the PC or hub.
When using a USB connection, connect one end of the USB cable to the USB client
port and the other end to the PC.
The USB host port is used for connecting the cradle with other USB peripheral device.
PC
PC or hub
5. Turn on the power switch on the right side of the Ethernet Cradle. The power
indicator LED on the front of the Ethernet Cradle lights red.
6. Hold the V-T500 so that the bottom faces downwards and fi t it into the Ethernet
Cradle so that the mount hooks in the cradle engage the mount holes in the V-T500.
The power indicator LED on the front of the Ethernet Cradle will light green if the
V-T500 has been properly mounted.
Hole
Hook
