Bluetooth
Bluetooth Low Energy chip: 2x nRF52840
Bluetooth Low Energy version: 4.0/4.1/4.2/5.0
Connections: up to 40 co-existing connections
Frequency: 2.400 to 2.483 GHz
Data rates: up to 2x2 Mbps
Tx power: configurable in 3~19dBm (limited by local regulatory requirements)
Rx sensitivity: -105dBm
Antenna Gain: 5.7dbi vertical polarized
External Bluetooth antenna (optional): 50 Ohm N type female connector. The antenna
and cable should have N type male connector
Wi-Fi (802.11 a/b/g/n/ac)
Frequency: 2.4GHz and 5GHz ISM band
Working Mode: Wi-Fi client or hotspot (for setup only)
Tx power: 12.5 to 17.5dBm for 2.4GHz, 8.5 to 15.5dBm for 5GHz
Rx sensitivity: -96 to -71dBm for 2.4GHz band, -91 to -71dBm for 5GHz band
depending on the modulation
Antenna: Integrated dual-band
For full features and specifications, please see the X2000 datasheet here:
https://www.cassianetworks.com/resources/x2000-bluetooth-edge-gateway/
1.2.
Cassia X1000
The Cassia X1000 enterprise Bluetooth gateway has an IP65-rated enclosure and may be
deployed in indoor and outdoor environments. The X1000 can be attached to a pole or wall
(a mounting kit is included) or placed on a surface like a desk or counter space. It receives
power from Power-over-Ethernet (PoE) via the uplink Ethernet port.
Cassia X1000 Bluetooth Gateway
The X1000 has a built-in smart antenna array designed specifically for Bluetooth. It also
supports Ethernet, 2.4 GHz Wi-Fi, or USB cellular modem as IP uplink. The X1000 is capable
