of extending Bluetooth’s range up to 1000 feet (300 meters).
The X1000 increases the number of devices that can be simultaneously paired and
connected to 22 Bluetooth low energy devices. It can also listen to potentially hundreds of
devices at the same time when operating in broadcast mode.
Processor & Memory
CPU: 4 core ARM Cortex-A5, up to 1.5GHz
256MB RAM DDR3, 4GB eMMC storage
Bluetooth
Bluetooth Low Energy chip: 2x CSR8811
Bluetooth Low Energy version: 4.0/4.1
Connections: Up to 22 co-existing connections
Frequency: 2.400 to 2.483 GHz
Data rates: up to 2x1Mbps
Tx power: Configurable in 5~20dBm (limited by local regulatory requirements)
Rx sensitivity: -105dBm
Antenna Gain: 5.7dbi vertical polarized
Wi-Fi (802.11 b/g/n)
Frequency: 2.4 GHz
Working Mode: Wi-Fi client or hotspot (for setup only)
Tx power: 12.5 to 17.5dBm
Rx sensitivity: -96 to -71dBm
Antenna: Omnidirectional
For full features and specifications, please see the X1000 datasheet here:
https://www.cassianetworks.com/resources/x1000-enterprise-bluetooth-router-en/
1.3.
Cassia E1000
The Cassia E1000 is an enterprise Bluetooth gateway with edge computing capabilities
specifically designed for deployments in industrial, hospitals, senior centers, schools, gyms,
and other indoor locations. The Cassia E1000 can be attached to the ceiling or wall (a
mounting kit is included) or may be placed on a desktop or counter space. The E1000 is
powered via a Micro-USB adapter or from a switch using Power over Ethernet via the uplink
Ethernet port.
