Copyright 2023 Cassia Networks, Inc.
Version: EN-2023039-YJ
Model Technology & Bands Data Rate Carriers Supported SIM Card Form Factor Countries/Regions Certified Size Supported Environmental Comments
HSAP+ / UMTS / EDGE / GPRS / GSM
3G (UMTS): B1 (2100 MHz), B2 (1900 MHz),
B5 (850 MHz), B8 (900 MHz)
2G (GSM): B2 (1900 MHz), B3 (1800 MHz),
B8 (900 MHz), B5 (850 MHz)
3G (UMTS HSPA+): 21.6 Mbps, HSPA: 14.4 Mbps,
HSDPA: 7.2 Mbps, HSUPA: 5.76 Mbps
2G (GSM EDGE): 236.8 Kbps, GPRS: 85.6 Kbps
Vodaphone, AT&T, T-Mobile, etc.
UMTS/HSPA Multi-Carrier GSM
Certified
Global Certifications
China, European Economic Area,
USA, Canada, Malaysia, Taiwan,
South Africa, Mexico, Argentina,
South Korea, Japan, Australia /
New Zealand, Israel, EAC
Economic Union (Russia, Belarus,
Kazakhstan, Armenia and
Kyrgyzstan)
84.9 mm x 27 mm x 12.3 mm 1.4.3 +
Huawei E3372s-153 (also known as T-
Mobile/Telekom Speedstick LTE V)
Huwei E3372h-153
4G (LTE): B20/B8/B3/B1/B7
(800/900/1800/2100/2600 MHz)
3G (UMTS): 900/2100 MHz
2G (GSM): 850/900/1800/1900 MHz
4G (LTE FDD): DL: 150 Mbps / UL: 50 Mbps @20
MHz Bandwidth
3G (UMTS DCHSPA+): 42 Mbps / 5.76 Mbps;
21Mbps / 5.76 Mbps; 14 Mbps / 5.76 Mbps;
HSUPA: 7.2 Mbps / 5.76 Mbps
2G (GSM EDGE): up to 236.8 Kbps
T-Mobile, Other carriers like
Vodafone if the cellular modem has
no SIM lock.
European Economic Area 88 mm x 28 mm x 11.5 mm 1.4.3 +
Huawei E8372h-153 (Europe)
Huawei E8372h-155 (China)
Huawei E8372h-320 (Europe, added
in firmware v2.1.1)
Huawei E8372h-820 (China, added
in firmware v2.1.1)
LTE / DC-HSPA+ / HSPA+ / HSPA / UMTS /
EDGE / GPRS / GSM
4G (LTE): B1 (2100 MHz), B3 (1800 MHz),
B7 (2600 MHz), B8 (900 MHz), B20 (800
MHz). TD-LTE B39/40/41 for E8372h-
155/820 only. FDD-LTE B5 for E8372-320
only
3G (UMTS): B1 (2100 MHz), B8 (900 MHz)
2G (GSM): 850 MHz / 900 MHz / 1800 MHz
/ 1900 MHz
Wi-Fi Hotspot: WLAN 2.5 GHz (802.11b,
802.11g, 802.11n); Supports up to 10 Wi-Fi
users.
4G (LTE FDD): up to DL 150 Mbps and UL 50 Mbps
@20 MHz Bandwidth
3G (UMTS DC-HSPA+): downlink up to 43.2 Mbps
3G (UMTS HSUPA): uplink up to 5.76 Mbps
2G (GSM EDGE): up to DL 296 Kbps and UL 236.8
Kbps
Multiple Carriers Mini SIM (2FF) European Economic Area, China 94 mm x 30 mm x 14 mm
1.4.3 +
E8372h-
320/820
from 2.1.1
Cassia router can connect to this modem
via WiFi.
4G LTE (LTE - LTE-U, CAT 6; US bands:
B2/B4/B5/B13; Global bands: B3; Carrier
Aggregation: B13+B4, B13+B2, B4+B2,
B4+B4, B2+B2, B2+B5, B4+B5. Quad band -
GPRS/EDGE; Quad band UMTS/HSPA;
CDMA2000 1xRTT / EvDOrA)
3G (UMTS): B1 / B2 / B5 / B8
3G (CDMA EV-DO): BC0 (800 Mhz) / BC1
(1900 Mhz PCS)
2G (GSM): B2 / B3 / B5 / B8
Up to 300 Mbps downlink and 50 Mbps uplink Verizon Nano SIM (4FF) USA, Canada
83 mm x 35 mm x 11.4 mm (not
including USB connector)
After the USB cellular modem
configuration is completed on the AC or
router console, please make sure to
power-cycle the router or unplug and re-
plug in the USB cellular modem.
In order to fit the USB730L into the
bottom enclosure of the X1000, the USB
connector of U730L should be turned
over. Please see the User Manual for
instructions. Search for "Novatel
USB730L" and look at the NOTE
comments.
4G (LTE CAT M1): B4 (AWS 1700 Mhz), B13
(700 Mhz)
Up to 300 Kbps downlink and 375 Kbps uplink Verizon Mini SIM (2FF) USA, Canada
78.7 mm x 40.1 mm x 18.8 mm
(not including USB cable)
Operating temperature:
-40° to +122° F (-40° to +50° C)
Storage temperature:
-40° to +185° F (-40° to +85° C)
Humidity:
Relative humidity 15% to 93%
noncondensing
LTE CAT M1 only modems. They can only
access the cellular network where LTE
CAT M1 is enabled. What is more, the
router upgrade may take more than one
hour because limited CAT M1 throughput.
4G (LTE CAT M1)
Verizon: B4 (AWS 1700 Mhz), B13 (700
Mhz)
AT&T: B2 (1900 Mhz), B4 (AWS 1700 Mhz),
B12 (700 Mhz)
Same as MultiTech MTD-MVW1
Verizon, AT&T and other cellular
operators
Mini SIM (2FF) USA, Canada Same as MultiTech MTD-MVW1 1.4.3 +
Same as MultiTech MTD-
MVW1
LTE CAT M1 only modems. They can only
access the cellular network where LTE
CAT M1 is enabled. What is more, the
router upgrade may take more than one
hour because limited CAT M1 throughput
4G (LTE CAT 1): B2(1900MHz), B4 (AWS
1700MHz), B5 (850MHz), B12 / B13
(700MHz)
3G (UMTS): B2 (1900MHz), B5 (850MHz)
Up to 10 Mbps downlink and 5 Mbps uplink
AT&T, T-Mobile, and other cellular
operators
Micro SIM (3FF) USA, Canada
53.5 mm x 45.5 mm x 19.8 mm
without antenna (please use
flexible ribbon antennas if you
want to put MTCM-LAT3-B03
inside X1000 enclosure)
Storage and operating
temperature:
-40° to +185° F (-40° to +85° C)
Humidity:
Relative humidity 15% to 85%
noncondensing
If customer wants to put this in the X1000,
they need ribbon cable antennas.
MultiTech MTCM-LNA3-B03 Same as MultiTech MTCM-LAT3-B03 Same as MultiTech MTCM-LAT3-B03
Verizon, AT&T, T-Mobile, and other
cellular operators
Micro SIM (3FF) USA, Canada
Same as MultiTech MTCM-LAT3-
B03
Same as MultiTech MTCM-
LAT3-B03
If customer wants to put this in the X1000,
they need ribbon cable antennas.
MultiTech MTCM-LSP3-B03 Same as MultiTech MTCM-LAT3-B03 Same as MultiTech MTCM-LAT3-B03 Sprint Micro SIM (3FF) USA, Canada
Same as MultiTech MTCM-LAT3-
B03
Same as MultiTech MTCM-
LAT3-B03
If customer wants to put this in the X1000,
they need ribbon cable antennas.
4G (LTE FDD): B1 (2100 MHz), B2 (1900
MHz), B3 (1800 MHz), B4 (AWS 1700 MHz),
B5 (850 MHz), B7 (2600 MHz), B8 (900
MHz), B12/B13 (700 MHz), B18 (850 MHz),
B19 (850 MHz), B20 (800 MHz), B25 (1900
MHz), B26 (850 MHz), B28 (700 MHz)
4G (LTE TDD): B38 (2600 MHz), B39 (1900
MHz), B40 (2300 MHz), B41 (2500 MHz)
3G (UMTS): B1 (2100 MHz), B2 (1900 MHz),
B4 (AWS 1700 MHz), B5 (850 MHz), B6 (800
MHz), B8 (900 MHz), B19 (850 MHz)
2G (GSM): B2 (1900 MHz), B3 (1800 MHz),
B5 (850 MHz), B8 (900 MHz)
Up to 150 Mbps downlink and 50 Mbps uplink
Vodafone, Telefonica, Orange, and
other EU operators
European Economic Area/
European Union
62.2 mm x 45.4 mm x 19.8 mm
without antenna (please use
flexible ribbon antennas if you
want to put MTCM2-L4G1 inside
X1000 enclosure)
Storage and operating
temperature:
-40° to +185° F (-40° to +85° C)
Humidity:
Relative humidity 15% to 85%
noncondensing
If customer wants to put this in the X1000,
they need ribbon cable antennas.
4G (LTE CAT 1): B4 (AWS 1700 Mhz), B13
(700 Mhz)
Up to 10 Mbps downlink and 5 Mbps uplink Verizon Micro SIM (3FF) USA
80.9 mm x 50.4 mm x 15 mm
(without antenna)
Operating temperature:
-22° to +140° F (-30° to +60° C)
Storage temperature:
-40° to +185° F (-40° to +85° C)
Humidity:
5% to 95%
May have heat issues encapsulated in the
X1000 bottom cap. Better to use outside
of the router.
4G (LTE CAT 1): B2/B4/B5/B12
3G (UMTS): 850 MHz / 1700 MHz / AWS
2100 MHz / 1900 MHz
LTE CAT 1: up to 10 Mbps downlink and 5 Mbps
uplink
HSPA: up to 7.2 Mbps downlink and 5.76 Mbps
uplink
AT&T, T-Mobile, and other Cellular
operators
Micro SIM (3FF) USA Same as Zoom ZoomCell 4615 1.4.3 + Same as Zoom ZoomCell 4615
May have heat issues encapsulated in the
X1000 bottom cap. Better to use outside
of the router.
ConnectedIO EM1000T-VZ-CAT1
4G (LTE CAT 1): B2 (1900 MHz), B4 (1700
MHz), B13 (700 MHz)
Up to 10 Mbps downlink and 5 Mbps uplink Verizon Mini SIM (2FF) USA
84 mm x 57 mm x 17.79 mm
without antenna (please put
EM1000T-VZ-CAT1 outside of
X1000 enclosure)
Operating temperature:
-22° to +185° F (-30° to +85°C)
This is too big for the X1000 bottom cap.
Place it outside of the router.
Power input: 5V DC 0.5A
4G (LTE): 800/1500/1800/2100 MHz
3G (UMTS): 800/850/2100 MHz
2G (GSM): 850/900/1800/1900 MHz
DoCoMo Micro SIM (3FF) Japan
88 mm x 30 mm x 12.2 mm (not
including USB connector)
Operating temperature:
14° to 122° F (-10° C to 50° C)
Humidity:
15% to 90%
Can't use Softbank's SIM card
