C16QS Hardware Manual
43
USIM_VDD
44
USIM_RST
45
USIM_DATA
46
USIM_CLK
47
GND
48
GND
49
ANT_GNSS
50
GND
51
RESERVED
52
VBAT_RF
53
VBAT_RF
54
GND
55
GND
56
RESERVED
57
RESERVED
58
GND
59
GND
60
ANT_LTE
61
GND
62
GND
63
I2S_BLK
64
AGPIO7
65
RESERVED
66
RESERVED
67
GND
68
GND
69
GND
70
GND
71
GND
72
GND
73
GND
74
GND
75
NET_STATUS
76
RESERVED
77
RESERVED
78
RESERVED
79
GND
80
GND
81
GND
82
GND
83
GNSS_RXD
84
GNSS_TXD
85
GNSS_VDD
86
GNSS_EN
87
RESERVED
88
RESERVED
89
GND
90
GND
91
GND
92
SWDIO
