C16QS Hardware Manual
NOTE
• Only GPIO7 is available for toggling via AT command (AT+GPSET=0/1).
3.9 Network Status Indication Interface
The C16QS module provides an open-drain GPIO signal to indicate the status of the RF communication.
3.9.1 Network Status
C16QS provides two network status indication pins: NET_STATUS (Pins 21 & 75). These pins are used to
drive a network status indication LED. Since both the pins have the same functionality, use only one and
keep the other floating.
The following tables describe the pin definition and logic level changes of NETLIGHT in different network
activity status.
Table 1-14 Network Indicator Pin Definition
Table 3-15 Network Indication Status
Pin
Signal name
I/O
Description
21
NET_STATUS /
USB_BOOT
DO
Network status indication
75
NET_STATUS
DO
Network status indication
Status
LED display status
No service
OFF
Searching for Network
Flashing
The module registers 4G network or module to register
non-4G network for voice SMS and other services (Latched
on to Network)
Constantly Bright
