C16QS Hardware Manual
5 Interface Electrical Characteristics
5.1 Chapter Overview
• Working storage temperature
• Electrostatic property
• Reliability index
• Module IO level
• Power supply
• Power consumption characteristics
5.2 Working Storage Temperature
Table 5-1 C16QS module working storage temperature
5.3 Electrostatic Property
There is no overvoltage protection inside the C16QS module.
The ESD protection is required when the module is used to ensure product quality.
ESD design recommendations:
✓ The USB port needs to add TVS on VDD, D+, D- for protection, and the TVS parasitic capacitance on
D+/D- is <2pF
✓ The module's USIM card external pin needs to be protected by TVS, and the parasitic capacitance
requirement is <10pF
Parameter
Minimum
Maximum
Normal operating temperature
-20°C
55°C
Storage temperature
-45°C
90°C
