C16QS Hardware Manual
3.2.2 C16QS Pin Interface
The C16QS module has the LGA interface. The module interface definition is shown in the following table:
Table 3-1 Pin name
Pin
No.
Pin name
Pin
No.
Pin name
1
RESERVED
2
ADC1
3
GND
4
I2S_MCLK
5
I2S_LRCK
6
I2S_DIN
7
I2S_DOUT
8
RESERVED
9
USB_DP
10
USB_DM
11
GPIO1
12
RESERVED
13
RESERVED
14
RESERVED
15
PWRKEY_N
16
RESERVED
17
RSTN
18
W_DISABLE
19
AP_READY
20
STATUS
21
USB_BOOT/NET_STATUS
22
UART2_RXD
23
UART2_TXD
24
ADC0
25
AGPIO5
26
GPIO7
27
UART0_TXD
28
UART0_RXD
29
VDD_EXT
30
UART1_DTR
31
GND
32
VBAT_BB
33
VBAT_BB
34
UART1_RXD
35
UART1_TXD
36
UART1_CTS
37
UART1_RTS
38
UART1_DCD
39
UART1_R1
40
I2C_SCL
41
I2C_SDA
42
USIM_PRESENCE
