C16QS Hardware Manual
4.4 Antenna Requirements
C16QS Module Antenna Design Requirements:
Table 4-3 Antenna indicator requirements
Frequency
band
Standing wave
ratio
Antenna
gain
Effectiveness
TRP
TIS
B1 FDD
<2:1
〉-2.5dbi
〉40%
>16.5
<-88
B2 FDD
<2:1
〉-2.5dbi
〉40%
>16.5
<-88
B3 FDD
<2:1
〉-2.5dbi
〉40%
>16.5
<-88
B4 FDD
<2:1
〉-2.5dbi
〉40%
>16.5
<-88
B5 FDD
<2:1
〉-2.5dbi
〉40%
>16.5
<-88
B7 FDD
<2:1
〉-2.5dbi
〉40%
>16.5
<-88
B8 FDD
<2:1
〉-2.5dbi
〉40%
>16.5
<-88
B12 FDD
<2:1
〉-2.5dbi
〉40%
>16.5
<-88
B13 FDD
<2:1
〉-2.5dbi
〉40%
>16.5
<-88
B18 FDD
<2:1
〉-2.5dbi
〉40%
>16.5
<-88
B19 FDD
<2:1
〉-2.5dbi
〉40%
>16.5
<-88
B20 FDD
<2:1
〉-2.5dbi
〉40%
>16.5
<-88
B26 FDD
<2:1
〉-2.5dbi
〉40%
>16.5
<-88
B28 FDD
<2:1
〉-2.5dbi
〉40%
>16.5
<-88
B66 FDD
<2:1
〉-2.5dbi
〉40%
>16.5
<-88
