Cavli Wireless C16QS - GNSS Performances

48
www.cavliwireless.com
C16QS Hardware Manual
4.3 GNSS Performances
C16QS Module GNSS performance parameters:
Table 4-2 GNSS performance parameters
Features
Description
Receiving Bands
✓ GPS L1/ Galileo E1 C/A: 1575.42 Mhz
✓ GLONASS L1 C/A: 1602.5625 MHz
✓ BD2 B1 C/A: 1561.098 MHz
✓ SBAS: WAAS, EGNOS, MSAS, GAGAN
✓ NAVIC C/A: 1176.45 MHz
Horizontal Positioning Accuracy:
< 2.0 m CEP50
Vertical Positioning accuracy
< 3.0 m CEP50
Velocity Accuracy:
Without Aid: < 0.01 m/s
TTFF@-130dBm
✓ Cold Start < 28s
✓ Hot Start ≤ 1s
✓ Reacquisition ≤ 1 s
Sensitivity:
✓ Cold Start: -147 dBm
✓ Tracking: -160 dBm
✓ Hot Start: -155 dBm
✓ Reacquisition: -158 dBm
LTE B28
703 MHz - 748 MHz
758 MHz - 803 MHz
FDD
LTE B66
1710 MHz - 1780 MHz
2110 MHz - 2200 MHz
FDD
