Lay the Case Assembly Glue on
balancer cover
※Glue diameter about 1mm
Install balancer cover , then
screw the bolts
※The bolts torque 10Nm
Lay the Case Assembly Glue on
oil sump cover
※Glue diameter about 2mm
Lay the Bolt Glue on drive yoke
bolt , then install drive yoke
※The bolts torque 20Nm
77
