Install the CVT drive pulley , then
screw the bolt
※The bolts torque 120Nm
Install the driven pulley , then
screw the bolt
※The bolts torque 45Nm
Screw the Belt Removal Tool to
end to open the driven pulley ,
then install the belt
Install oil sump , then screw the
bolts
※The bolts torque 10Nm
78
