8 Control – normal operation
During normal operation the machine has an operator at each end. An operator who pushes the wood items
into the machine and another operator who takes the items once they have been painted/treated and come
out of the machine.
The painting machine’s controls are placed on the side of the machine at the intake. The main switch is
placed on the control board.
Start/stop - normal operation:
The machine is started/stopped during normal operation by turning buttons “PUMP”, “FORWARD DRIVE”
and “BRUSHES” to position 1 and 2 respectively. These are used for normal start/stop at e.g. breaks,
change of paint, etc. Please note that the pump function on machines with air powered membrane pump is
stopped by disconnecting the air supply to the pump.
Regulation of forward drive speed:
The speed of the forward drive of the items can be adjusted on the button ”FORWARD DRIVE”.
Regulation of brush speed:
The rotation speed of the brushes can be adjusted on the button ”BRUSHES”.
Stop:
For stops for moving, repairs, maintenance and disassembly the main switch on the control board must be
set to position 0 (the power is disconnected).
8.1 Emergency stop
The machine is equipped with a wire emergency stop at each end which ensures that the machine
stops when activated. When emergency stop is activated the brushes and forward drive are
stopped.
After emergency stop has been activated the machine can only be restarted with repeated activation of the
start button.
NB: Before the machine is started again you must make sure that the accident has been stopped and that
the reason for the activation of the emergency stop is known.
NEVER USE THE EMERGENCY STOPS AS A REGULAR STOP
FUNCTION
