11.3.3 Toothed belt for vertical brushes
Tensioning of belt for vertical brushes is carried out the following way:
· The fixed lid is dismantled
· 4 bolts on motor (1) are loosened
· Motor is displaced until belt (2) has sufficient tension
· 4 bolts on motor are tightened
· The fixed lid is remounted
