4 General information
4.1 Manufacturer
Ceetec A/S
Industrivej 7
DK – 5580 Nr. Aaby
Tel.: +45 64 42 14 73
e-mail: info@ceetec.dk
4.2 Machine information
Machine type: Painting machine
Type designation: IP250
Type no.: 053
4.3 Capacity
Max. item dimensions Width 250mm x height 100mm
Min. item length 1000mm
Capacity: Not relevant (depends on the operator)
4.4 Technical data
Forward drive speed App 30-60 meters/min (depending on parameter setup on frequency converter)
Pump capacity App. 20-80 litres/min (depending on pump type)
Motor connection 3x380V. IP class 54
Power forward drive 0.75 kW. 50 HZ
Power brushes 2 x 0.37 kW. 50 HZ
Power pump 0.37 kW. 50 HZ
4.5 Weight
Own weight: App. 525kg
4.6 Noise conditions
Noise level: The painting machine does not produce noise in excess of the allowed 80 dB
(A). Thus, use of hearing protectors is not necessary.
