12.2 Toothed belt for forward drive
Replacement of belt for forward drive is carried out the following way:
· Bolt on tension pulley (1) is loosened
· The tension pulley is loosened until the belt (2) is loose
· Old belt (2) is dismounted and new belt is mounted
· Tension pulley is tensioned (belt is tensioned)
· Bolt on tension pulley is tightened
