Ceetec IP250 - Spare Parts Overview

Page 35 of 45
13 Spare parts overview
See general views after the list
Item no. Description Amount/machine Picture
9021-20500 Ceetec IP250 1
9015-20535 Intake guide – 1 set 1 A
9012-50584 Spindle for overpressure roller 2 A
9012-20515
Chain wheel for overpressure
roller 2 A
9021-20501 Chain for overpressure roller 1 A
9015-20531
Bronze bush for spindle for
overpressure roller - bottom 2 A
9015-20530
Bronze bush for spindle for
overpressure roller – top 2 A
9021-20502 Axle for overpressure roller 1 A
9021-20503 Bearing for overpressure roller 2 A
9021-20504 Overpressure roller, complete 1 A
9015-20536 Handle for overpressure roller 1 A
9011-20645 Nozzle - 3 mm (std.) 9 B
9011-20642
End sleeve (end plug) for nozzle
pipe 4 B
9011-20652 Nozzle pipe, top, complete 1 B
9011-20692 Nozzle pipe, bottom, complete 1 B
9011-20691 Nozzle pipe, vertical, complete 2 B
0450302 Instant coupling, alu – female 4 B
0450011 Instant coupling NV 24 (male) 4 B
9011-20593 Valve for nozzles 4 B
9021-20505
Instant coupling for nozzle box
(large) female 1 B
9021-20506
O-ring for large instant coupling
on nozzle box 1 B
9021-20507 Nozzle box, complete 1 B
