Page 33 of 45
12.3 Toothed belt for vertical brushes
Replacement of belt for vertical brushes is carried out the following way:
· The fixed lid is dismounted
· 4 bolts on motor (1) are loosened
· Motor is displaced (belt is loosened) and the belt (2) is dismounted
· New belt is mounted
· Motor is displaced (belt is tensioned)
· 4 bolts on motor are tightened
· The fixed lid is mounted
