CONTROLLER FEATURESSECTION 25
24.6. Menu 7 - Pedestrian Opening
This feature is associated with the PED input on the Controller, and can be
activated using the onboard multichannel receiver. When activating this input, the
system will open the gate to the Pedestrian Open position, and then automatically
close after the Pedestrian Autoclose time lapses. If the PED connection to Com
is maintained, then the gate will remain open, and when the connection is broken,
it will close after the Pedestrian Autoclose time has expired.
The time taken for the gate to open to pedestrian is dependent on the pedestrian
Pre-open Delay and the time required for the gate to close from the pedestrian
position is dependent on the Pedestrian Pre-close Delay.
25.6.1. Pedestrian Open Position
Sets the maximum opening of the pedestrian gate as a percentage of total travel.
25.6.2. Pedestrian Autoclose Time
Sets the Autoclose time in seconds after the gate has reached the Pedestrian
Open Position. This time can be set from zero seconds to four minutes in one
second increments.
25.6.3. Pedestrian Pre-open Delay
Sets the time delay between the Pedestrian Opening input being activated and the
gate commencing movement. This enhances safety in cases where the pedestrian
has to reach through the gate in order to activate the pedestrian input. This delay
can be set from zero seconds to four minutes in one second increments.
A Warning Light would typically be active during this delay.
25.6.4. Pedestrian Pre-close Delay
Sets the time delay between the Pedestrian Autoclose timer expiring, and the
gate actually closing. This delay can be set from zero seconds to four minutes in one
second increments.
• A Warning Light would typically be active during this delay
• The Warning Light is any light wired to the Pillar Light contacts,
as described in Menu 9
